芘(129-00-0)紅外圖譜(IR1)
InChI:InChI=1S/C16H10/c1-3-11-7-9-13-5-2-6-14-10-8-12(4-1)15(11)16(13)14/h1-10H
InChIKey: BBEAQIROQSPTKN-UHFFFAOYSA-N
Smiles:C1=C2C3=C4C(C=C2)=CC=CC4=CC=C3C=C1
-
Assign. Shift(ppm)
A 8.161
B 8.054
C 7.987
J(A,C)=7.6HZ.
Spectral Code: 1H NMR : 400 MHz in CDCl3
-
ppm Int. Assign.
131.04 550 5
127.25 980 4
125.70 500 3
124.81 1000 2
124.58 165 1
Spectral Code: 13C NMR : in CDCl3
-
Spectral Code: IR : KBr disc
-
Spectral Code: ESR : ANION RADICAL, REDUCTION WITH LI
