1,1-二苯基-2-苦味酰肼(1707-75-1)核磁圖(1HNMR)
分子式:C18H13N5O6
分子量: 395.33
InChI:InChI=1S/C18H13N5O6/c24-21(25)15-11-16(22(26)27)18(17(12-15)23(28)29)19-20(13-7-3-1-4-8-13)14-9-5-2-6-10-14/h1-12,19H
InChIKey: WCBPJVKVIMMEQC-UHFFFAOYSA-N
Smiles:N(C1=CC=CC=C1)(C1=CC=CC=C1)NC1=C([N+]([O-])=O)C=C([N+]([O-])=O)C=C1[N+]([O-])=O
-
Assign. Shift(ppm)
A 11.01
B 8.874
C 7.44 to 7.04
Spectral Code: 1H NMR : 90 MHz in DMSO-d6
-
ppm Int. Assign.
146.00 238 1
142.03 126 2
140.06 39 3 *
136.49 101 4
133.62 42 5 *
129.58 995 6
126.29 83 7 #
125.88 492 8
125.03 56 9 #
120.51 1000 10
Spectral Code: 13C NMR : in CDCl3
-
Spectral Code: IR : nujol mull
-
Spectral Code: ESR : ANION RADICAL, REDUCTION WITH K IN DME
