1,3,5-均三苯甲酰氯(4422-95-1)核磁圖(1HNMR)
分子式:C9H3Cl3O3
分子量: 265.48
InChI:InChI=1S/C9H3Cl3O3/c10-7(13)4-1-5(8(11)14)3-6(2-4)9(12)15/h1-3H
InChIKey: UWCPYKQBIPYOLX-UHFFFAOYSA-N
Smiles:C1(C(Cl)=O)=CC(C(Cl)=O)=CC(C(Cl)=O)=C1
-
Mass
MS-IW-1295
1,3,5-benzenetricarboxylic acid trichloride
C9H3Cl3O3 (Mass of molecular ion: 264)
Source Temperature: 140 °C
Sample Temperature: 100 °C
Direct, 75 eV
37.0 2.9
37.5 2.0
50.0 1.3
51.5 3.4
53.0 1.1
65.0 2.1
65.5 4.7
73.0 2.6
74.0 11.1
75.0 18.4
76.0 1.2
97.0 5.4
98.0 1.8
103.0 4.7
109.0 2.3
110.0 2.1
137.0 4.0
138.0 7.3
139.0 1.8
140.0 2.4
165.0 10.2
166.0 23.1
167.0 5.4
168.0 7.7
201.0 5.5
203.0 3.6
229.0 100.0
230.0 10.0
231.0 65.4
232.0 6.4
233.0 11.1
234.0 1.1
-
| 1H NMR |
300 MHz |
| C9 H3 Cl3 O3
|
0.038 g : 0.5 ml CDCl3
|
| 1,3,5-benzenetricarboxylic acid trichloride
|
 |
Parameter ppm Hz
D(A) 9.094
|
Hz ppm Int.
2728.20 9.094 1000
