3'-甲基-4-二甲氨基偶氮苯(55-80-1)核磁圖(13CNMR)
InChI:InChI=1S/C15H17N3/c1-12-5-4-6-14(11-12)17-16-13-7-9-15(10-8-13)18(2)3/h4-11H,1-3H3
InChIKey: LVTFSVIRYMXRSR-UHFFFAOYSA-N
Smiles:C1(N(C)C)=CC=C(N=NC2=CC=CC(C)=C2)C=C1
-
ppm Int. Assign.
153.27 242 1 *
152.28 280 2 *
143.65 237 3
138.59 414 4
130.10 366 5
128.68 409 6
124.81 796 7
122.33 435 8
119.78 462 9
111.42 1000 10
40.08 785 11
21.34 312 12
Spectral Code: 13C NMR : in CDCl3
